Husqvarna P 525DX Front Deck Mower with cabin
£27,539.19 (Inc VAT) - incl. VAT
Contact for availability 01423 780319 enquiries@jtodd.co.uk
A commercial-grade, diesel-powered front mower supplied deckless with a factory-assembled cabin. The front-mounted cutting position gives the operator an unobstructed view for close trimming, while the compact articulated chassis and All‑Wheel Drive deliver manoeuvrability and traction across confined and uneven sites. The cabin is anti‑vibrated, removable and fitted with heating, lights and a high-spec Grammer seat for year‑round use.
Exceptional manoeuvrability
Articulated steering lets the rear wheels swing under the machine for a minimal turning radius. The compact design suits narrow paths, around benches and in confined urban areas.
Reliable traction and slope stability
All‑Wheel Drive with a low centre of gravity provides automatic traction adjustment and improved stability on wet, uneven ground and hills. Commercial‑graded transmission components are specified for heavy use.
Operator comfort for long shifts
Anti‑vibrated cabin with glass doors, roof front window and a high‑spec Grammer seat reduces noise and vibration. Heated cabin, road lights and LED work lights extend operating capability through colder months and low light.
Key specification
| Article ID | 967985401 |
| Transmission | Hydrostatic |
Full specification
| Weight (excl. cutting equipment) | 918 kg |
| Battery Chemistry | Lead-Acid |
| Cylinder displacement (metric) | 1123 cm³ |
| Connectivity | BLE-HAPP |
| Exhaust emissions (CO₂ EU V) | 1018 g/kWh |
| Sound pressure level at operators ear (LpA) | 91 dB(A) |
| Sound power level, guaranteed (LWA) | 105 dB(A) |
| Sound power level, measured | 104 dB(A) |
| Battery capacity | 62 Ah |
| Cutting height max (metric) | 112 mm |
| Cutting height min (metric) | 30 mm |
| Power/fuel type | Diesel |
| Serie | 500-serie |
| Cylinders | 3 |
| Net power at preset rpm Energy | 17.8 kW |
| Engine brand | Kubota |
| Net power at preset rpm | 3000 rpm |
| Engine name | D1105 |
| Transmission type | Hydrostatic |
| Motor/engine manufacturer | Kubota |
| Base machine, length (metric) | 226.9 cm |
| Base machine, width (metric) | 115.3 cm |
| Base machine, height (metric) | 200.8 cm |
| Engine cooling | Liquid |
| Engine lubrication type | Pressure with Oilfilter |
| Oil filter | Yes |
| PTO (Power Take Off) | Shaft drive |
| Transmission manufacturer, rear | Kanzaki |
| Drive method | Dual pedal-operation |
| Speed forward max (metric) | 19 km/h |
| Speed reverse max (metric) | 15 km/h |
| Transmission manufacturer, front | Kanzaki |
| Transmission model, front | KTM 23LC |
| Transmission model, rear | KTM 23SC |
| Uncut circle (metric) | 58 cm |
| Cutting width, min (metric) | 132 cm |
| Cutting width, max (metric) | 155 cm |
| Blade engagement | Electric clutch |
| Seat suspension | Yes |
| Seat type | Full suspension, arm rests |
| Hour meter type | Digital |
| Seat material | Vinyl |
| Seat back height | High |
| Foldable seat | Yes |
| Steering wheel type | Professional |
| Parking brake, type | Disc |
| Tyre dimensions, front | 20×10-10 |
| Tyre dimensions, rear | 20×10-10 |
| Wheelbase (metric) | 106 cm |
| Ground clearance (metric) | 140 mm |
| Gross weight towed (metric) | 100 kg |
| Vibration level steering wheel | 1.7 m/s² |
| Vibration level seat | 0.7 m/s² |
| Drive system | All-wheel drive |
| Steering knob | Standard |
Key features
Unique articulated steering
The unique articulated steering system allows the rear pair of wheels to swing in underneath the machine. The result is superior manoeuvrability with a minimum turning radius at full lock.
All-Wheel-Drive (AWD)
All-Wheel-Drive (AWD) ensures traction on uneven, wet and slippery areas and slopes. AWD automatically adjusts the traction on all wheels depending on situation and ground condition.
Commercial graded transmission
High-specified variable piston pumps with separate gear boxes for front and rear axle.
Compact design
The compact size together with the unique articulated steering makes it easy to manoeuvre the machine in narrow spaces and tricky areas.
All-Wheel Drive (AWD)
The machine’s low centre of gravity in combination with the high-performing AWD-system gives excellent slope and hillside stability.
Versatile usage
A wide range of cutting decks and accessories makes our Riders exceptionally versatile, all year round.
Trimming ability
The front-mounted cutting deck gives excellent overview of the working area, enabling precise, close-up trimming.
Shaft PTO
Solid and hardened PTO axle for maximum efficiency and durability.
Quick coupling
Unique quick coupling allows attachments to be changed quickly and efficently without tools.
Kubota diesel engine
High performance 3-cylinder Kubota diesel engine with full pressure lubrication. Combines exceptional power and torque with fuel efficiency and reduced emissions.
Ergonomic operation
Ergonomic operator’s interface for a comfortable ride during long working hours.
Hydraulic power steering
Heavy-duty hydraulic-cylinder power steering makes driving less strenuous.
Mowing accessibility
The low profile front-mounted cutting deck gives unbeatable accessibility in under fences, bushes, park benches etc.
Easy-access controls
Controls are easy accessible and designed for optimum user comfort.
Easy access
The tilting hood and easy-access servicing points make maintenance and servicing easy.
Greasable mandrels
For easy maintenance and longer lifetime.
Off-set cutting deck
For easy handling of corners and close-up trimming against walls and fences.
Service position
Service position on the cutting deck facilitates cleaning and service.
Durable ladder frame
Heavy-duty steel ladder frame with reinforcements combined with an open design for excellent serviceability.
Cast iron rear wagon
For improved durability the complete rear wagon is in one piece ductile cast iron.
Product video
FAQs
Will this fit my machine?
Fitment can vary by model and deck size. Send us your mower model (and deck size if applicable) and we’ll confirm compatibility before you order.
Do I need any extra brackets or fitting kits?
Some accessories require a mounting kit or specific brackets depending on your machine. If you’re unsure, ask us and we’ll advise the correct setup.
Can you fit it for me?
Yes — if you’d like installation, let us know when ordering and we can arrange fitting (collection, workshop fit, or on-site depending on the product).
Is a cutting deck included with the P 525DX with cabin?
No. The machine is delivered deckless and can be fitted with 132 cm or 155 cm Combi cutting decks depending on your application.
Can the cabin be removed for summer use?
Yes. The cabin is designed to be easily removed from the chassis if you prefer to operate without it in warmer months.
How does it handle slopes and slippery conditions?
All‑Wheel Drive automatically adjusts traction across the wheels and, combined with the machine’s low centre of gravity, provides good slope and hillside stability for typical municipal and contractor tasks.
Additional information
| Weight | 918.000 g |
|---|---|
| UPC|EAN | 7392930295346 |
