Practical, durable ride-on designed for larger lawns. The R 214TC combines a twin‑cylinder HV 586AE engine with a 94 cm Combi cutting deck, offering BioClip® mulching and rear ejection. It’s built for easy operation, straightforward maintenance and good manoeuvrability around obstacles — the sort of machine I recommend when you need reliable, everyday performance rather than specialist features.
Twin‑cylinder power and torque
The rear‑mounted HV 586AE twin‑cylinder engine (586 cm³, 12 kW at 2,900 rpm) gives steady power for consistent cutting and better noise and emission separation from the driver’s area.
Combi cutting deck for two cutting modes
The 94 cm Combi deck lets you choose BioClip® mulching for frequent cuts and natural lawn fertilisation, or rear ejection when grass is higher or tougher — practical flexibility without changing machines.
Comfortable operator environment
Ergonomic steering, a high‑back comfort seat with suspension and easy‑access controls keep you comfortable during longer jobs. The low centre of gravity also improves stability on gentle slopes.
Key specification
| Article ID | 970542301 |
| Transmission | Hydrostatic |
Full specification
| IsNew | No |
| Weight (excl. cutting equipment) | 207 kg |
| SpareParts | 536313601, 590844201, 598581801, 591165901, 531147110, 579652510, 599675902, 594977801, 589530701, 589531201, 544442101, 576384102, 576384103, 544064901, 577041601, 501604804, 506963001, 506869601, 506533101, 586966401, 584248702, 536982801 |
| Accessories | 587024701, 953534901, 501008201, 953511703, 586636501, 953512401, 586636702, 586636601, 546081001, 546080801, 593676701, 505630870, PIM70523, PIM142693 |
| Battery Chemistry | Lead-Acid |
| Cylinder displacement (metric) | 586 cm³ |
| Connectivity | Not applicable |
| Exhaust emissions (CO₂ EU V) | 778 g/kWh |
| Sound pressure level at operators ear (LpA) | 83 dB(A) |
| Sound power level, guaranteed (LWA) | 98 dB(A) |
| Power source | Petrol |
| Sound power level, measured | 97 dB(A) |
| Battery capacity | 24 Ah |
| Cutting height max (metric) | 75 mm |
| Cutting height min (metric) | 25 mm |
| Cylinders | 2 |
| Net power at preset rpm Energy | 12 kW |
| Engine brand | Husqvarna |
| Net power at preset rpm | 2900 rpm |
| Engine name | HV 586AE |
| Transmission type | Hydrostatic |
| Motor/engine manufacturer | Husqvarna |
| Base machine, length (metric) | 223 cm |
| Base machine, width (metric) | 100 cm |
| Base machine, height (metric) | 107 cm |
| Engine cooling | Air |
| Engine lubrication type | Pressure with Oilfilter |
| Oil filter | Yes |
| PTO (Power Take Off) | Belt-driven |
| Drive method | Dual pedal-operation |
| Speed forward max (metric) | 9 km/h |
| Speed reverse max (metric) | 6 km/h |
| Uncut circle (metric) | 30 cm |
| Cutting width, min (metric) | 94 cm |
| Cutting width, max (metric) | 94 cm |
| Blade engagement | Automatic |
| Seat suspension | Yes |
| Seat type | Comfort |
| Hour meter type | Digital |
| Seat material | PU |
| Seat back height | High |
| Foldable seat | Yes |
| Steering wheel type | Ergonomic |
| Parking brake, type | Disc |
| Tyre dimensions, front | 170/60-8 |
| Tyre dimensions, rear | 170/60-8 |
| Wheelbase (metric) | 88.7 cm |
| Ground clearance (metric) | 105 mm |
| Gross weight towed (metric) | 110 kg |
| Vibration level steering wheel | 1.9 m/s² |
| Vibration level seat | 0.29 m/s² |
| Serie | 200-serie |
| Drive system | Rear wheel drive |
| Cutting deck type | Combi 94 |
| Steering knob | Optional |
Key features

Pivoting rear axle
The rear axle is pivoting to get maximum traction on the drive wheels and a smooth ride also on uneven surfaces.

Combi cutting deck
The Combi cutting deck allows you to choose between two cutting systems depending on the conditions. Choose BioClip® for lawn fertilisation and rear ejection for efficient mowing on areas with higher and rougher grass.

Comfortable driver’s position
With a Rider you get safety, stability and traction on both flat grounds and hillsides. The Rider’s low gravity centre contributes to extra good traction as well as a comfortable ‘sit-in’ feeling for the user.

Hour meter
Hour meter for easy control of operating time and service and maintenance intervals.

Unique articulated steering
The articulated steering gives excellent maneuverability and facilitates driving around obstacles such as trees and bushes. Since the rear pair of wheels can swing underneath the machine, the turning radius becomes minimal at full lock.

Four large wheels
16-inch wheels both front and back provide optimal riding comfort, great accessibility and less risk of damaging delicate surfaces.

Combi cutting deck with BioClip® (mulching)
BioClip® (mulching) provides perhaps the best cutting result on the market on frequently cut areas. The grass is cut into fine pieces that quickly turn into fertiliser.

Automatic blade engagement
The blades are engaged automatically when you lower the cutting deck for a quick and smooth start of work.

Easy-access controls
Controls are easy accessible and designed for optimum user comfort.

Turn key start
Easy to get operating under any weather condition and no choking needed. Just turn the key and go.

Versatile usage
A wide range of cutting decks and accessories makes our Riders exceptionally versatile, all year round.

Pedal-operated hydrostatic transmission
Pedal-operated hydrostatic transmission – speed and direction are managed by pedals, letting you keep both hands on the steering wheel for optimal driving control.

Front-mounted cutting deck
Front-mounted cutting deck for excellent accessibility into corners and under bushes, park benches etc.

Service position
The cutting deck can be tilted up into service position for easy access during cleaning or service.

Husqvarna Connect
With the smart Husqvarna Connect app, you’ll have easy access to helpful tips, manuals and spare part recommendations. For your connected Bluetooth equipment, the app also provides additional information such as runtime and charging status as well as maintenance and service needs. The app can be downloaded, free of charge, from App Store or Google Play.

Easy-access cutting height lever
The cutting height lever is easy to reach from the driver’s seat, making it possible to do cutting height changes while mowing.

Engine behind driver
The rear-mounted engine provides a better overview of the mowing, and less noise and emissions in the driver’s area, compared to riders with front-mounted engines.

Storage compartment
The open left storage makes it easy to access your items while mowing.

Bottle holder
Convenient bottle holder for refreshments.
Product video
FAQs
Will this fit my machine?
Fitment can vary by model and deck size. Send us your mower model (and deck size if applicable) and we’ll confirm compatibility before you order.
Do I need any extra brackets or fitting kits?
Some accessories require a mounting kit or specific brackets depending on your machine. If you’re unsure, ask us and we’ll advise the correct setup.
Can you fit it for me?
Yes — if you’d like installation, let us know when ordering and we can arrange fitting (collection, workshop fit, or on-site depending on the product).
When should I use BioClip® (mulching) and when should I use rear ejection?
Use BioClip® on frequently mown areas — it chops grass into fine pieces that act as a natural fertiliser. Switch to rear ejection when grass is taller, denser or contains more debris, as it clears clippings away for a cleaner finish.
How do I access the cutting deck for cleaning or service?
Park on level ground, apply the parking brake and stop the engine. The Combi deck can be tilted into its service position for cleaning and inspection; follow the operator manual for the correct procedure and safety checks before working under or around the deck.
How do I keep track of service intervals?
The hour meter records running time so you can plan maintenance. Use the hour readings alongside the operator manual recommendations and consult Husqvarna Connect for manuals and spare part information to schedule oil changes, filter checks and other routine work.
Additional information
| Weight | 243.000 g |
|---|---|
| UPC|EAN | 967846901 |
